Hurd Casement Part Identification Help & Information

Click on the picture above to enlarge. This will show you details for the Hurd Casement Window with replacement window part identification. Picture Key with Part identification and corresponding part # is shown below. If no part number is found, please call R&R for more info.

Hurd Casement Windows can be All Wood in-side and out or Aluminum Clad Exterior with Wood Interior.

Part very by Vintage - Hurd Casement Window Vintage:

Hurd Energy Saver Line has been manufactured from: 09/17/2007 to Present

Hurd Classic Line was manufactured from 02/02/1998 - 9/17/2007

Old Style Line was Manufactured Prior to 02/02/1998.

Hurd H3 line - H3 GEN I was manufactured from 2009 - 3/16/2016. H3 GEN II From 3/16/2016 - Present. H3 Parts have their own section. Please click on "H3 Line Parts" tab on the left-hand side of the page.

Each vintage of Hurd Casement used different type of window hardware and parts that where the best available at the time. Some window parts can be upgrade with newer style replacement parts and will be noted in the description, but others cannot be upgraded.

If you do not know what vintage of Hurd Casement Window you have, that is not a problem. We include pictures of all the replacement window parts and window hardware which you can match up to your existing awning window part.

Picture Key:

1. Operating Wood Sill Stop, Upper Section Frame - Part # 103 103 - Casement Bottom Sill Cover

2. Operating Wood Sill Stop, Lower Section - Frame

3. Sill Stop Blocks

4. Hinge Side Wood Stop

5. Lock Side Wood Stop

6. Lock Side Support Stops

7. Operating Wood Head Stop

8. Hinge Track - Part # 121 121 - Hinge Arm and Track Assembly Kit

9. Hinge Arm Sash - Part # 121 121 - Hinge Arm and Track Assembly Kit

11. Dual Arm Operator Frame - #119, #147 #158 - Older Vintage #101, #102, #111, #115, #109, #105

119 - Operator- Dual Arm-Encore - (9/19/05 to Present)

147 - Encore Operator-Dyad Sill Mounted (9/19/05 to Present)

158 - Operator Encore-Single Arm - (9/19/05 to Present)

101 - Operator-Dual Arm- DLX - (02/02/1998- 09/19/2005)

102 - DLX Split Arm Operator

111 - Operator - Split Arm Straight Link Casement Window Operator (1988 to 02-02-1998)

115 - Operator Short Arm 9 1/2" - (Prior to 1988)

109 - Operator -Short Arm (7 1/2") ( Prior To 1988)

105 - Operator- Long Arm (13 1/2") ( Prior To 1988)

12. Encore Handle Frame - #137 (only can be used on # 119, 147, #158) 137 - Encore Folding Handle and Operator Cover - Kit - (9/19/05 to Present) BULK PRICING

13. Sash Bracket Sash - Part# 187 - Older Vintage # 123

187 - Sash Bracket with Set Ring

123 - Sash Bracket - NO Set Ring

14. Lock Handle Frame - Part # 129-ELL OR 129-KIT- Older Vintage Lock #179, #125, #179-

15. Keeper Sash - Part # 113 - Older Vintage # 143

16. Lock Escutcheon Frame - Part # 129-ELE OR # 129-Kit

17. Tie Bar w/ Link & Guides Frame - Part # 198

18. Dual Arm Sash Track Sash

19. Dual Arm Sash Track Shoe Sash - Part # 189

20. Snubbers Frame / Sash

21. Encore Operator Cover Frame - Part # 137

22. Sash Lift Block Sash - Part # 106

23. Nailing Fin Corner Pads - Part # 964

24. Offset Bulb Weather-strip - Part # 902 - Older Vintage # 901 - All Wood #909

25. Sill Folding Nailing Fin - Part # 692

26. Head & Side Folding Nailing Fin - Part # 961

28. Frame Lift Block - Part # 107

30. Glass

29. Sash Tall Bulb Weather-strip - Part # 903 Energy Saver - Older Vintage #904-A / #903 Classic - All Wood #906

31. Screen Frame - Screen Corners #140 - Older Vintage# 141. Replacement Screens #CscreenKD or #CscreenA

32. Glazing Bead Sash - Part # 966. Older Vintages #930, #916, #914, # 913, #911

33. Complete Sash Operating / Stationary- Part # casement-wood-clad-sash OR #casement-sash-all-wood

Parts Not Shown on Exploded View:

• Hinge Clip Sash - Part # 212

• DLX Keeper Locator - Part #172

• Construction “T” Handle

• Truth Handles used on DLX and Prior - Part # 139, #177, #131, #135, #108

• Casement Hardware DLX 2/2/98 to 9/19/05 - Part # 101, #102

• Casement Hardware (1988 - 2/2/1998) Split Arm Operator - Part # 111

• Handed Sash Lock and Keepers - Part # 113

• Casement Operator Prior to 1988 - Part # 105, #115, #109

• Sash Alignment Snubber

• Anti Bow Clip

• Sash Limit Device - Part # 191

• Structural Nail Fin

• "C" Hinge Shim - Part # 183 - For Non adjustable Hinges

• Adjustable Hinge Wrench- Part # 190 - For adjustable Hinges
