Part Number: 307 Clutch Pin
Metal Clutch Pin for Compression Tilt Double Hung and Single Hung Jamb Liners.
Current style is the direct replacement for the old style. Screw hole and spoke are in the same location and size. See pictures that show old vs current style.
Old style Size: 5/8" wide x 1 1/4" Tall - Spoke protrudes out 1/2"
Material: Metal
Used On: Biltbest, Hurd, WeatherSheild, Caradco and many other window brands.
Associated Parts Sold Separately:
Part Number 308 Clutch Shoe
Part # 308 Clutch Shoe Pack
Compression Tilt Double Hung Windows
Measures 2-3/8" (or 2 13/32") x 1/2" x 15/32"
Color: White
Used On: Biltbest, Hurd, WeatherSheild, Caradco and many other window brands.
Known Part Number: H 4036
Associated parts Sold separately:
Part Number 335 Balance Spring
Part Number 307 Clutch Pin Pack
Part Number: 315
Sold Individually
now come non handed works for both left and right latch application
Tilt Latch Set For Double Hung and Single Hung Window
Tilt Latch Set for Single or Double Hung - Can be used for top or bottom sash. In stock Colors: Champagne, Goldtone, White and Bronze
Special Order Colors: Matt Black, Antique Brass, Bright Brass, Brushed Chrome, Polished Chrome, Satin Nickel, Oil Rubbed Bronze* (Special order items are a no returns or order cancellation item once order is placed. Lead times very based on product availably at factory you can email or text us before you place an order and we can check with the factory for lead time).
*Oil Rubbed Bronzed is a FB "faux bronze" painted finish.NOTE: Old style will be shipped until inventory is depleted and then we will ship new style. See picture.Set comes with: 1 left and 1 right
Part Number: 317
Snap In Tilt Latches Vinyl Double Hung and Single Hung Windows Set Includes: 1 left & 1 RightColors: White and Dark Brown (Dark Chocolate Brown in color).Discounted Colors: Beige (Light Tan/Almond color no longer available)
Product Dimensions: 11/16" Wide x 2 12/31" Long x 27/64" Deep
Can be used on top or bottom sash. This tilt latch is a 85 Series Balance Accessories
Known to been used on Hurd Monument Vinyl Double Hung and Single Hung windows and variety of other vinyl window brands that used the 85 Series Balance System.Known Part Numbers: 317, V00380, V00381, V00382, V00383
PAT. # 5,139,291
Part Number: 320
Tilt Pivot Pint Set for Classic and Premium Tilt Double Hung Windows
sold individually
Fits Hurd Classic and Premium Tilt SH & DH, Wood & Clad, with Vinyl JamblinersDIM: 1 3/8 x 1/8 x 5/8 DeepThis Tilt Pivot Pin was used with T-Lock Shoe (Part # 324) and 1 1/4" Block and Tackle Shoe (Part # 325)
Fits Hurd Classic and Premium Tilt SH & DH, Wood & Clad, with Vinyl Jambliners
321 Sash Lift Handle - Double Hung Windows
For glass width over 24" 2 sash lifts per window are recommended by manufacture.Other Finishes Available - Special Order Only - Email or Text R&R for Finishes and Price
Part number: 324
T-Lock Shoe
Puck and sides that are extended color: Green
Cam: open
sold individually Tilt Double Hung Windows 2 are required per windowPart # 328 - Tilt Pivot Pin - is for T-lock Shoe.
Part Number: 325
Omega Lock Pivot Shoe 1 1/4 Inch Block and Tackle Shoesold individually
Double Hung Jamb Liner Part
Associated Parts Sold Separately:
Tilt Pin (Pivot Pin) Part # 320. This tilt pin is what fits into Part # 325. 1 1/4" Block and Tackle Link Part # 326 (white plastic pc only). This fits into Part# 325.
Part Number: 326 - 1 1/4" Black and Tackle Link Pack Premium Tilt1 1/4" Block and Tackle Link Premium Double Hung Jamb Liner Part
Size Packs:
2 pack (QTY 2 per pack)
6 pack (QTY 6 per pack)
10 pack (QTY 10 per pack)
1 1/4" Block and Tackle Shoe Part # 325 This fits into Part# 326. Tilt Pin (Pivot Pin) Part # 320. This tilt pin is what fits into Part # 325.
Part Number: 327
327 is a discontinued Item once we are out of stock their replacement will be part number 710
Snap On Balance Shoe Pack for Concealed Jamb liner
Style:
327 Old Style - Once we are out of stock you will replace with 701
710 New Style - to order go to 710 product page. comes with new rivet pin as 710 is longer and mounts in the 2nd old of your balance bar. If you do not have the rivet installation tool you will also need to order it. Part Number: Coming Soon is Sold Separately (see guide replacement instructions)
CDH Snap On Balance Shoe
Concealed Jamb Liner Double Hung Windows, Hurd and H3 Windows.
Part Number 710 Accessories sold Separately:
S2021 - Rivet Installation Tool
S2022 - Sash balance guide rivets
