Amesbury Truth 190 Wrench for Adjustable Hinge Tracks 31887 14 Series Casement Hinges- Truth Hardware Wrench For Adjustable Hinge Studs
Part Number: 190 In Stock! Free Shipping! Amesbury Truth Wrench for 14 Series Casement Hinges that have Adjustable hinge tracks - Truth Hardware Wrench For Adjustable Hinge Studs - Low Profile Adjustable Stud Hinge Wrench, 8/10-4/18 This wrench only works on Truth adjustable hinges as shown in the pictures. If your hinge don’t look exactly like the picture shows this wrench will not work on your hinge (please scroll thru all pictures to compare with your hinge). Wrench Size is: 7/16" on the straight side and 3/8" on the angled side - Number on part 31887, For adjusting Hinge part #s 121, 122. Adjustment Instructions For Sash Drag: Remove Screen Open the window Slip the adjustment wrench onto the base of the stud, found between the support arm and the track of the lower hinge. Rotating the wrench away from the lock side of the window will decrease the amount of sash drag. The maximum sash drag adjustment is reached when the stud flats are parallel to the track. For severe sash drag, a similar procedure can be used on the upper hinge. Upper hinge adjustment is made by rotating the wrench toward the lock side of the window. Maximum adjustment is obtained when the stud flats are parallel to the track. Close and open window to check for proper adjustment. NOTE: Turning the stud flats beyond parallel will not increase sash drag correction. maximum adjustment may cause binding as the window is closed. Please use caution. Use Proper PPE (gloves safety glasses) when preforming repair and maintenance tasks. If you feel you are not able to preform repair and maintenance tasks contact a local window service technician in your area. Known Part Number: HA6806MI, 31887, V982164
Part # 119 Casement Operator - Encore Dual Arm Sill Mount Amesbury Truth 50.10 119 is the Operator Only - You will need to purchase the cover and handle kit part number 137 sold separately. Manufacture Details: Encore Operators give you all the strength and performance characteristics of Maxim, but with the flexibility of a snap-fit cover and streamlined full-flip folding handle that eliminates collapse during operation. Encore Operators require 33% less effort to operate than previous operators and are designed to use the same mounting location as the Maxim system. Stainless steel components are available for coastal applications. These operators complement the Encore Multi-Point Locking System. Finish Arms available in: Standard E-Gard Beige (stock) and Stainless Steel (Non stock)* *Non stock items are special order and can have a 2-6 week lead time. orders can not be cancelled or returned. Associated Parts Sold Separately: Part Number: 137 Encore Folding Handle and Cover Kit Part # 187 - Sash Bracket with Set Ring - elbow arm of #101 operator snaps onto Part # 189 - Track Shoe – what the long arm of the #101 operator snaps onto Part # 114 - Sash Track (what the track shoe #189 slides into) Part # 121 - Adjustable Hinge – below the operator on the bottom and on top of the window when you open it. Known to have been used on the following Manufacturing Brands: Hurd, Semco, Marvin, Cascade, BiltBest, Milgard, Sierra Pacific Monarch April 2006 to present and more. Manufacture Tech Note: Proper Installation of an Operator Cover & Nested Folding Handle. When installing the cover and handle on the operator you should follow theseinstructions:• Snap the cover onto the operator base.• Place the handle onto the spline of the operator and rotate the handle to closethe window.• Lock the window in place.• Rotate the handle Ľ turn back (towards opening direction) to reduce thepressure on the operator.• If the handle needs to be positioned in a nested cover you can remove thehandle at this time and re-position it so that it will rest correctly in the nestedcover.• Tighten the set screw on the handle.• Unlock the window and cycle the sash open and closed until the handle returnsto the starting position whereby there is no additional torque required to close the sash. Note: the sash should travel to a point that the lock can easily engageand seal the window.• If the window does not come all the way into the closed position, and more forceis required on the operator to close the window, you will need to review thewindow for the following; sash sag; racked window; lock points that are notproperly aligned; or hinges not installed correctly. These issues should becorrected prior to repeating the installation of the handle onto the operatorspline.Placing the operator and the handle under high stress and abusive loads can causepermanent failures to the handle or operator as the window is repeatedly opened andclosed. Known Part Numbers: 119, 096357, 096358, 36-368EN, 36-369-EN updated 7/8/23
$ 49.00 - $ 69.00
Amesbury Truth 129 Amesbury Truth Mirage Lever Lock & Escutcheon Kit
Part Number 129 MIRAGE® CONCEALED MULTI-POINT LOCKING SYSTEM Casement and Awning Amesbury Truth Mirage Lever Lock & Escutcheon Kit Each Kit Comes With: 1 lever Lock and 1 escutcheon The true beauty is what you can't see. Mirage's Concealed Locks for wood windows are so thin; they're barely noticeable. All locking points are concealed to create a clean look for your window system. The handle and escutcheon are removable for painting or staining wood trim. The tie bar guides are pre-located for quick and easy installation. Mirage's Multi-Point Locking System has an exceptional .625" pull-in and can withstand 245 lbs. of force per locking point. In Stock Colors: Champagne, White, New Goldtone, Bronze, Black All other colors are special order item. No returns or exchanges. Associated parts Sold Separately: Bug Guards can also be purchased separately P/N 128 pack of 4 BACKPLATE LINK ASSEMBLY (11645.92) 198 Tie Bar Multi Point Window Locking Mechanism (in jamb version) Brand: Amesbury Truth Mirage, Energy Saver Vintage Hurd Casement and Awning, Sierra Pacific, H3 and many other window brands, Energy Saver Vintage Hurd Casement and Awning Kit Includes: Lock Handle, Escutcheon and 2 Bug Guards Known Part Numbers: 45265, 45376, 10-13 Sash Lock (B1), HCSE66, D4-2091, D4-2092, D4-2090
$ 19.00 - $ 52.00
Amesbury Truth S1015 -Amesbury Truth Residential SafeGard 2R Window Operating Control Device (WOCD) For Casement Windows
Part Number: S1015 Residential SafeGard 2R - Current Style Amesbury Truth Residential SafeGard™ 2R Operating Control Device (WOCD) For Casement Windows The easy to operate SafeGard 2 is designed to limit the window opening to less than 4”. Designed to allow for factory installation as well as field application by trained personnel. Fits in the standard hinge cavity of 0.719"W x 0.438"H (nominal). Arm assembly has a decal with simple operating instructions, and track is assembled with visible colored plastic to discern the separate operations. . This patented releasable limit device for windows meets the ASTM F2090 (window fall prevention) safety requirements for self-resetting, egress capable, fall prevention devices. Handing: Left Hand (Stamped with letter "A") or Right Hand (Stamped with letter "B") ****Determine handing by the hinge side of your window from the exterior. When looking at your window from the OUTSIDE of your home if it is hinged on the LEFT then you need a LEFT Hand WOCD)**** Style: We recommend to check with your window manufacture which style to purchase for your window. R2 Standard -Track (with black clip and red button): 8 11/16 Inch Long x 3/4 Inch Wide x 1/4 Inch Deep R2 Narrow - Track (with black clip and red button): 7 1/16 Inch Long x 3/4" Wide x 1/4" Deep (For comparison the old Gen 1 Safegard Style with Red clip that is no longer available size was: 6 3/8" Long x 3/4" Wide X 1/4" Deep C2 For pricing and to order C2 Commercial WODC for 5/8” cavity please email us with how many Left and and Right hand you would want for quote. Safeguard 2R Installation Instructions PDF Ordering Instructions for SafeGard 2R: Residential Applications 1. Determine window handing by viewing from the outside looking in. If the casement window hinge is on the right side, you need a right hand limiting device. 2. The self-locating sash device is designed for a 7/16 in. [11 mm] cavity. Ensure there are no lips or ribs that would block the ability of the sash device to engage with the frame device. Consult the window manufacturer or application if cavity is larger than 7/16 in. [11 mm] or if lips /ribs are present, or if the cavity height on the jamb is significantly different than the sill. Shims may be required. 2.1. Locate the hinge cavity by finding where the hinge arm attaches to bottom of sash. Follow this cavity around the corner of the sash to the vertical sash member 2.1.1. If there is no cavity on the vertical sash member, please consult with your window manufacturer for application review. Includes: Arm Assembly, Track Assembly, Template, Window Label, Screw Pack (4 screws) and Operating and Installation Instructions. (Recommended screws are #8 Pan Head, Length and screw type depended on application). Product Highlights Product will limit the window opening to less than 4” and requires two actions to release the device allowing the window to open fully for egress purposes WOCD and egress release will not reduce the open area of the window unit beyond applicable code requirements Avoids interference with operation or performance of a window Features and Benefits beyond ASTM F2090-21 Fully concealed unit after installation and window in closed position Easy and accurate installation in the factory or field for residential applications (SafeGard™2R) and factory or field commercial applications (SafeGard™2C) Built-in forgiveness with field adjustment feature and allowing for up to 1/8” sash sag All adjustments can be done inside the home after window is installed Pan head screw (SS) use for ease of handling Concealed arm after released from track Window Opening Control Devices as required by ASTM F2090-21, the standard specification for window control devices with emergency (egress) release mechanisms Actions to release the device for egress purposes are to be performed without the use of keys, tools or special knowledge WOCD will automatically re-latch when window is fully closed Recommended Mounting Screws. #8 Pan Head, length and screw type dependent on application Safegard 2R Residential Application Info: As a market leader in fenestration hardware, AT engineered, patented, and manufactured a releasable limit device for windows which meets the ASTM F2090 safety requirements for self-resetting, egress capable, fall prevention devices. The ASTM F2090 addresses window fall prevention that helps protect against potential falls by children through open windows. This is done by allowing the window opening to be set at a predetermined position of fewer than four inches (4”) and automatically re-latch when fully closed. AmesburyTruth’s SafeGard™ 2R provides a means that the window, when opened in an initial operation, will limit the venting to less than 4”. By code, two actions are required to open the window fully for egress purposes. This additional operation can be performed without the use of keys, tools, or special knowledge. SafeGard™ Window Opening Control Device is designed to allow for factory installation as well as field application by trained personnel. PRODUCT TIPS 1. We recommend that a casement WOCD be used in casement application where applicable and building codes require such application. Please check the local building codes for applicability and egress size requirements. 2. Casement WOCD can be factory installed or field retrofit on all profile material types where standard/nominal (0.719” W X 0.438”H) hinge cavity is available. Please observe all safety instructions and consult window manufacturer when you have questions or concerns. Please contact sales for application to ensure form, fit, and function for your specific window application 3. Standard 2 walls (vinyl, fiberglass, aluminum, and other composite materials) on the profile are required for proper screw retention 4. Correct handing with proper installation is important to ensure proper operation of the device ARCHITECT SPECS Window Opening Control Devices as required by ASTM F2090-21, the standard specification for window control devices with emergency (egress) release mechanisms. Product will limit the window opening to less than 4” and requires two actions to release the device allowing the window to open fully for egress purposes. Actions to release the device for egress purposes are to be performed without the use of keys, tools, or special knowledge. WOCD will automatically re-latch when window is fully closed. This WOCD shall be “SafeGardTM Casement The easy to operate SafeGard 2R is designed to limit the casement window opening to less than 4”. This patented releasable limit device for windows meets the ASTM F2090-21 (window fall prevention) safety requirements for self-resetting, egress capable, fall prevention devices. Arm assembly has a decal with simple operating instructions, and track is assembled with visible colored plastic to discern the separate operations. Designed to allow for factory installation as well as field application by trained personnel. Fits in the standard hinge cavity of 0.719"W x 0.438"H (nominal). Meets ASTM F2090-21, with additional benefits Prohibits the free passage of a 4” diameter rigid sphere Requires two separate actions to release the mechanism WOCD and egress release will not reduce the open area of the window unit beyond code requirements Avoids interference with operation or performance of window Fully concealed when window is closed Easy, accurate factory install. Field adjustment features allows for up to 1/8” sash sag adjustment from inside the home Suitable for wood, composite and vinyl windows Window Type Casement Window Material: Wood Composite Vinyl Recommended Mounting Screws #8 Pan Head, length and screw type dependent on application Current Safegard 2 Video Below Old Style No Longer With Red Clip Video Below- this style is no longer available replacement is the S1015
Amesbury Truth 189 Track Shoe For Casement Windows
Part Number 189 Track Shoe For Casement Windows - Comes in Black Only - Also called casement slider for operator Dimension: 11/16" Black Casement Slider Amesbury Truth Replacement Part that attaches to Truth Operators: Related Products Sold Separately: Part # 101 - Amesbury Truth Maxim DLX Sill Mount Casement Dual Arm Operator Part # 187 - Sash Bracket with Set Ring - elbow arm of #101 operator snaps onto Part # 114 - Sash Track (what the track shoe #189 slides into) Part # 121 - Adjustable Hinge – below the operator on the bottom and on top of the window when you open it
AmesburyTruth 918/713 Amesbury Truth Kerf Mounted Gray Hollow Bulb Foam Filled Window Weather Strip Seals
Part # 918/713 AmesburyTruth Weatherstrip with Hollow Off-White Foam Filled - .300 Window Seal Color: Gray, White, Bronze, Sand. Sold by the foot Rolled: Larger QTY's maybe shipped in multiple rolls. Example if you order 300 feet you may receive QTY 6 - 50 foot rolls. Some rolls maybe in increments of 25 feet. (for full spool order 1250 feet) no returns of rolls of less than 25 feet Returns will only be accepted for full uncut rolls in increments of 25, 50 and 100 feet. For full spool order: 1250 Foot Spools - no returns on spools** **1250 Foot Spool can have a lead time if not in stock no order cancelations Bulk Pricing Calculated Once Added To Cart: QTY 25 - 49 Feet 45% QTY 50-99 Feet 55% QTY 100-499 Feet 65% QTY 500-999 Feet 75% QTY 1000+ Feet 80% Manufacture Detail: Compression seals are almost 100% closed cell to prevent water from getting into the foam cell structure. The exterior skin provides UV resistant barrier with design features that enhance the weather strip's sealing performance. Designed to fit .089" / .250 kerf slot Window Weather Strip Seals are an maintenance item. You should replace your weather strip every 10-15 years depending on your climate and weather conditions of the area you live in so windows seal properly. Known Brands: AmesburyTruth, Hurd Windows, Sierra Pacific Windows, H3 Windows and many other window brands. Known Part Numbers: 918, 039053, 12138112291250, 12138 Maintenance: Weather Strip Seals are an maintenance item. You should replace your weather strip periodically once it’s worn out so windows seal properly. Lifespan of weatherstripping depends on your climate, weather conditions of the area you live in, and other wear and tear factors that is put on the window.
Part Number: 902 As of April 2019 the old style (see picture) is no longer available. You will receive the new style which is the direct and closest replacement. Amesbury Truth Offset Kerf Mounted Foam Filled Seal Window Weather Strip Color: Gray Designed to fit .078"/.250 kerf slot Manufacture Detail: Compression seals are almost 100% closed cell to prevent water from getting into the foam cell structure. The exterior skin provides UV resistant barrier with design features that enhance the weather strip's sealing performance. Weather Strip Seals are an maintenance item. You should replace your weather strip every 10-15 years depending on your climate and weather conditions of the area you live in so windows seal properly. Sold by the foot Rolled: Larger QTY's maybe shipped in multiple rolls. Example if you order 300 feet you may receive QTY 6 - 50 foot rolls. Some rolls maybe in increments of 25 feet. (full spool comes in 1,500 feet only) no returns of rolls of less than 25 feet Returns will only be accepted for full uncut rolls in increments of 25, 50 and 100 feet. Spools of 1500 feel special order item no return and may have long lead time. Known Part Number: 902, 12029, 020546, 020545, HCSE443 Known Brands: Hurd Windows, AmesburyTruth, and many other window brands.
Amesbury Truth 135 Amesbury Truth 'T' Handle with 11/32 Inch Spline
Part # 135 Amesbury Truth T Crank Handle. Also called Wing handle or Butterfly Handle Crank Handle for Amesbury Truth 11/32 Spline Operators Used primarily on the DLX operator Replacement part for Hurd Casement and awing window operators Vintage Classic Style: 02/02/1998 - 9/17/2007 and many other window brands that use Truth Hardware Colors In Stock: Goldtone, Bronze, White, Clay, Aluminum, Black, New Goldtone, Oil Rubbed Bronze (this is a faux ORB), Special Order Colors: Chestnut Bronze, Brushed Copper Nickel, Off-White, Cocoa Brown, Bright White, (No returns 1 - 3 week lead time). Known Part Numbers: 136, Truth 40984, 021951, 37-125-2 Used on: Amsbruty Truth Operators, Norco, Hurd Casement and Awnings, Weather Sheild, and more. Replacement Parts for: Hurd, Semco, Marvin, Cascade, Caradco, BiltBest, Milgard, Sierra Pacific, Vetter and more.
$ 20.00 - $ 30.00
Part # 140 Discontinued product once our stock is gone they will no longer be available Replacement Hurd Corner Keys Screen Corner Square New Style For Casement and awning Hurd Energy Saver Window Screens. Dimensions: See photos with calipers showing size. We measure down to the 16th inch only for ease of measuring. Colors: Goldtone, White, Bronze and Champagne. Replacement window screen corners new style for Hurd Energy Save casement and awning window screens. Easy DIY Home Screen repair. We recommend replacing all four corners at a time Known Part Numbers: 140, 096258, 096259, 096256 You may also want to purchase the Screen and Spline Installation Tool Part # 998 . Please see Parts – Miscellaneous Tab . Below how to video is showing a differing screen comer to application is the same for the 140
835 - 4" x 4" Ashland Horizontal Guide Hinge Adjusting Swinging Patio Door Hinge PIVOT TRUE V400 4" ADJUSTABLE HORIZONTAL DOOR HINGES For the Mate Vertical Hinge see part number 836 Low Stocked Item - May have a 2-3 week lead time KEY FEATURES Seamlessly retrofits a 4" X 4" one-step pocket route with 5/8" corner radius Hex head adjustment screws, not Phillips or Slotted, to provide secure tool engagement and prevent stripping during adjustment Screw hole locations optimized away from panel edge to prevent accidental wood splitting Panel leaf incorporates a unique shield to keep out debris and provide a premium appearance in the closed position Incorporates Teflon filled bushings for increased wear resistance Non-removable pin (NRP) option available for secure out-swing applications PERFORMANCE AND OPERATION Adjusts 1/4" vertically and 3/16" horizontally Easily reversible for either left or right-hand hinge applications Innovative, patent-pending adjustment mechanism achieves extremely low adjustment torque with a standard 3/32" hex wrench Exceeds BHMA - grade 3 standards for wood, vinyl, aluminum and steel doors. Known Brands: Ashland, Hurd Energy Saver Patio Door, Sierra Pacific WI Patio Door Screw Pack: Screws are sold separately and not all colors are available. To order Screws with your hinges see 835/836Screw Pack (1 screw pack will do 1 hinge). Or you can buy at your local hardware store the following: QTY 4 - #9 x ¾” or 1” (size change depends on what finish the screw is available in) QTY 4 - #9 x 1-1/2” QTY 1 - #9 x 2 ½” or 3” (size change depends on what finish the screw is available in IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU.
$ 38.00 - $ 95.00
part number: 406 For Hurd Monument Horizontal Slider Windows sold by the foot, and 50 foot rolls no returns on orders less than 50 feet. Returns for full uncut 50 foot rolls only.
$ 5.00 - $ 55.00
Amesbury Truth 213 Black Slider Shoe
Part number: 213 Pivot Slide Assembly - Black Plastic Dimensions 1 1/4" x 1 1/16" Black Slider Shoe for Awning DLX Maxim and Encore OperatorsReplacement Part for awning window operator.Amesbury Truth Replacement Part Associated Parts Sold Separately: Part Number: 718 - Amesbury Truth Awning Guide Bar Part Number: 207 Amesbury Truth Encore Sill Mount Awning Operator Part Number: 209 Amesbury Truth Maxim DLX Awning Operator
