Part Number 137 Truth Amesbury Encore: Tango Folding Handle and Operator Cover for Casements and Awning Operators  13342 12616 Handing: Casements can be left or right handed See pictures above, video and Pro Tip below to determine handing you need to order for your operator. Awnings operators will always will be Left Hand. Colors: New Goldtone, Champagne (old Prior to 4/1/2024), Current Champagne (4/1/2024 to Present), Coppertone, Bronze, White, Black, Bright Brass, Polished Chrome, Brushed Chrome, Brushed Nickel, Antique Brass, Oil Rubbed Bronze, Beige Out of stock / Pre Order Colors  can have a estimated 2-6 week lead time. Price depends on finish selected. Large QTY orders may not be eligible for returns.  Pro Tip: Left Hand = White Bag to be used with Silver Worm Operator.  Right Hand = Red Bag to be used with Gold Worm Operator. Encore Operators Sold Separately: Part Number: 119  Casement Encore Dual Arm Sill Mount Amesbury Truth  Part Number:  147 AmesburyTruth Encore Sill Mount Casement Operator-Dyad Part Number: 158 AmesburyTruth Casement Sill Mount Operator-Encore-Single Arm Part Number: 207 Awning Amesbury Truth Encore Awning Sill Mount Operator. Proper Installation of an Operator Cover & Nested Folding Handle: When installing the cover and handle on the operator you should follow these instructions: • Snap the cover onto the operator base. • Place the handle onto the spline of the operator and rotate the handle to close the window. • Lock the window in place. • Rotate the handle ¼ turn back (towards opening direction) to reduce the pressure on the operator . • If the handle needs to be positioned in a nested cover you can remove the handle at this time and re-position it so that it will rest correctly in the nested cover. • Tighten the set screw on the handle. • Unlock the window and cycle the sash open and closed until the handle returns to the starting position whereby there is no additional torque required to close the sash. Note: the sash should travel to a point that the lock can easily engage and seal the window. • If the window does not come all the way into the closed position, and more force is required on the operator to close the window, you will need to review the window for the following; sash sag; racked window; lock points that are not properly aligned; or hinges not installed correctly. These issues should be corrected prior to repeating the installation of the handle onto the operator spline. Placing the operator and the handle under high stress and abusive loads can cause permanent failures to the handle or operator as the window is repeatedly opened and closed. This video will show how to determine which handing to 137 cover and handle to order for your operator:  This video will show how to attached # 137 Encore Cover and handle to the # 119 Truth Encore Operator Manufacture Tech Note: Proper Installation of an Operator Cover & Nested Folding Handle. When installing the cover and handle on the operator you should follow theseinstructions:• Snap the cover onto the operator base.• Place the handle onto the spline of the operator and rotate the handle to closethe window.• Lock the window in place.• Rotate the handle Ľ turn back (towards opening direction) to reduce thepressure on the operator.• If the handle needs to be positioned in a nested cover you can remove thehandle at this time and re-position it so that it will rest correctly in the nestedcover.• Tighten the set screw on the handle.• Unlock the window and cycle the sash open and closed until the handle returnsto the starting position whereby there is no additional torque required to close the sash. Note: the sash should travel to a point that the lock can easily engageand seal the window.• If the window does not come all the way into the closed position, and more forceis required on the operator to close the window, you will need to review thewindow for the following; sash sag; racked window; lock points that are notproperly aligned; or hinges not installed correctly. These issues should becorrected prior to repeating the installation of the handle onto the operatorspline.Placing the operator and the handle under high stress and abusive loads can causepermanent failures to the handle or operator as the window is repeatedly opened andclosed.   Known Part Numbers: 137, 096357, 096358, 096353, 096354, 096354, 096356,  13342 12616, HCSE54, MONCSE675 Known to have been used on the following brands: Hurd Operator cover and crank handle (nesting) for units manufactured 9/19/05 to present, Biltbest, Sierra pacific, Semco, Windsor, Lincoln, Comfort Line, Milgard, Fiber Frame, Monarch June 2006 to present and more

Read more less

Part # 119 Casement Operator  - Encore Dual Arm Sill Mount Amesbury Truth 50.10  119 is the Operator Only - You will need to purchase the cover and handle kit part number 137 sold separately. Manufacture Details: Encore Operators give you all the strength and performance characteristics of Maxim, but with the flexibility of a snap-fit cover and streamlined full-flip folding handle that eliminates collapse during operation. Encore Operators require 33% less effort to operate than previous operators and are designed to use the same mounting location as the Maxim system. Stainless steel components are available for coastal applications. These operators complement the Encore Multi-Point Locking System.  Finish Arms available in: Standard E-Gard Beige (stock) and Stainless Steel (Non stock)* *Non stock items are special order and can have a 2-6 week lead time. orders can not be cancelled or returned.  Associated Parts Sold Separately:  Part Number: 137 Encore Folding Handle and Cover Kit Part # 187 - Sash Bracket with Set Ring  - elbow arm of #101 operator snaps onto Part # 189 - Track Shoe – what the long arm of the #101 operator snaps onto Part # 114 - Sash Track (what the track shoe #189 slides into) Part # 121 - Adjustable Hinge – below the operator on the bottom and on top of the window when you open it. Known to have been used on the following Manufacturing Brands:  Hurd, Semco, Marvin, Cascade,  BiltBest, Milgard, Sierra Pacific Monarch April 2006 to present  and more.   Manufacture Tech Note: Proper Installation of an Operator Cover & Nested Folding Handle. When installing the cover and handle on the operator you should follow theseinstructions:• Snap the cover onto the operator base.• Place the handle onto the spline of the operator and rotate the handle to closethe window.• Lock the window in place.• Rotate the handle Ľ turn back (towards opening direction) to reduce thepressure on the operator.• If the handle needs to be positioned in a nested cover you can remove thehandle at this time and re-position it so that it will rest correctly in the nestedcover.• Tighten the set screw on the handle.• Unlock the window and cycle the sash open and closed until the handle returnsto the starting position whereby there is no additional torque required to close the sash. Note: the sash should travel to a point that the lock can easily engageand seal the window.• If the window does not come all the way into the closed position, and more forceis required on the operator to close the window, you will need to review thewindow for the following; sash sag; racked window; lock points that are notproperly aligned; or hinges not installed correctly. These issues should becorrected prior to repeating the installation of the handle onto the operatorspline.Placing the operator and the handle under high stress and abusive loads can causepermanent failures to the handle or operator as the window is repeatedly opened andclosed. Known Part Numbers: 119, 096357, 096358, 36-368EN, 36-369-EN updated 7/8/23

Read more less

Part Number 207 Amesbury Truth Encore Awning Sill Mount Operator. Replacement awning window operator 207 is the Operator Only - You will need to purchase the cover and handle kit part number 137 sold separately. Color: E-Guard or Stailless Steel (this refers to the arms of the operator)  Manufacture Details: Encore Operators give you all the strength and performance characteristics of Maxim, but with the flexibility of a snap-fit cover and streamlined full-flip folding handle that eliminates collapse during operation. Encore Operators require 33% less effort to operate than previous operators and are designed to use the same mounting location as the Maxim system. Stainless steel components are available for coastal applications. These operators complement the Encore Multi-Point Locking System. Recommended Screws: (Qty 6) 8 X 1 Flat Head Sheet Metal Screw  (Qty 2)Rear Mount:#8-32 X 3/8 Pan Head Machine Screw  Number Known to be stamped on back of arms: 41013 and 41016 Stamped on Back Side of Housing: Made In U.S.A Associated Parts Sold Separately:  Part Number: 137 Encore Folding Handle and Cover Kit Part Number: 718 - Amesbury Truth Awning Guide Bar Part Number: 213 Black Slider Shoe  Part Number: 212 Black Operator Retainer Clip updated 7/7/23

Read more less

Part Number: 989  Vinyl Window Sash Lock - Amesbury Truth Maxim Multipoint Lock with Gasket Amesbury Truth Casement and Awning Window Replacement Sash Lock Color: White Beige Size: Comes in 3 styles which is the "A" measurement on the drawing: 1-25/64 Inch 1-41/64 Inch 1-57/64 Inch Screw Hole Center to Center Measurement is 3 13/16" Screws not included. Factory recommended screws Qty 2 #10-24 PH PH thread forming machine screw.  Associated Parts Sold Separately:  984 - Amesbury Truth Window Lock Back Support Plate Used On: Amsbury Truth, Hurd Monument Vinyl and many other vinyl window brands known part number: 24.30, 24.31 and 24.33

Read more less

Part Number 984 Amesbury Truth Window Lock Back Support Plate Color: E-gard Beige  Comes in Packs of 1 or 5 Associated Parts Sold Separately:  989 Vinyl Window Sash Lock - Casement and Awning Windows Used On: Amsbury Truth, Hurd Monument Vinyl, Cascade Vinyl, SuperSeal  and many other vinyl window brands

Read more less

Part Number: S4202 Amesbury Truth Allure Series Gliding Door handle Set Only  (mortise lock box sold separately) Factory has in stock allow 1 week for you order to ship Style: Active with NO Key Color: White MOUNTING SCREWS: 2X #8-32 PHILLIPS OVAL HEAD MACHINE SCREWS (1.75, 2.125, AND 2.50 LENGTH SCREWS ARE PROVIDED IN THE KIT TO FIT STILE THICKNESSES RANGING FROM 1.25 TO 2.25). Known to have been used on Comfort Line FiberFrame and many other sliding patio doors, Part Number 40.85.32.100.1 Below are style of this handle set that is special order and will need to be quoted - please email us for quote info@windowpartscetner.com: Active with Key Dummy Other Colors and Finishes
