Part Number S1003
Old Style is DISCONTINUED PRODUCT NO LONGER AVAILABLE. The current style is the replacement option available per the factory - see pictures and compare drawings with dimensions.
Sash Pivot Pin Set - 1 LH 1 RH per Set
Zinc Die Cast
Replacement part for Weather Shield Double Hung and Single Hung (known part number 640008 and 640007)
If using current style: As this is a replacement option, we recommend buying 1 set to try and make sure it would work with you window application before ordering multiple sets.
This is a retro fit application, not a direct replacement. We have had multiple customers buy the current style and say they work as a replacement option for the old style pivot pin as long as the old style that is pictured on our website is what you have. If you feel that you are not able to retro fit the pivot pin we recommend customers contact a local a window service technician in your area.
Old Style Measurements:
Height: 1-3/4 inchWidth: 1/2 inchScrew Hole Spacing: 7/8 inch
Current Style Measurements:
Length: 1-15/32"Width: 7/16"
Part Number S1004
Truth's EntryGard Folding Handle Conversion Kit (see pictures)
Cover and Nesting Handle
Gives homes a new look in minutes!
Experience a convenient conversion with the S1004 EntryGard Cover and Nesting Handle Conversion Kit. Perfect for casement and awning windows, this kit provides an easy solution to replace old window handles and make them easy to operate – all from the comfort of your own home. Let us help you make the switch with our convenient and reliable conversion kit.
Converts crank handle to a folding / nesting handle. Just remove handle and cover, and install over operator housing.
Fits 15 Series EntryGard Casement and Awning Operator sold separately - See Accessories items
Colors: White, Bronze Clay and Coppertone Other finishes available. Please e-mail R&R for pricing and availability
Handing: Folding Handle System is Non-Handed. Fits all Entrygard operators.
Associated Parts Sold Separately:
Part Number 152 - Entrygard Dual arm casement operator
Part Number 117 - Entrygard straight arm casement operator
Part Number 176 - Entrygard dyad arm casement operator
Part Number S1113 - EntryGard awning operator 20.75
Part Number S1114 EntryGard Awning Operator 28.75
Part Number S1115 Entrygard Awning Guide Bar
Part Number: S1008
Balance Tensioning Tool for 83 and 85 Series spiral Balance
used to add tension to the spiral balance when installed on a single hung or double hung window
Styles: Classic or Deluxe
Part Number: S1008
Balance Tensioning Tool for 70, 72, 74, 75, 76 and 80 Balance Series
9 3/4 Inch Balance Tension Tool TOL 29
used to add tension to the spiral balance when installed on a single hung or double hung window
Caldwell MFG.
Part Number S1011
Amesbury Truth Encore Handle & Escutcheon
Color In Stock: White
Special order Colors Non Stock:* Almond Frost
Discontinued Color: Goldtone
Used on Biltbest, Marvin (Almond Frost) Casement and Awning windows and other window brands.
*For special order items please allow 3-6 weeks for your order to ship. Orders can not be cancelled or returned
Part Number: S1012
Peachtree Non-handed Casement Crank Operator Drag Link
Used on peachtree casement windows.
Handing: Non Handed
Style: Sill Mounted
Color: Black
***Crank handle sold separately see part # S1013***
Part Number: S1013
Replacement Peachtree Casement Operator Crank Handle
9/32 inch Spline
Color:
Driftwood
White
Bright Brass (plated)
Bright Brass is Special Order item allow 4 weeks to ship - no returns or order cancellations on specials order items
This crank handle goes onto casement window operator part # S1012 which is sold separately.
Part Number: S1014
Vent Lock -Window Operating Control Device (WOCD see code specification)
Key Operated Vent Lock - Vent Lock With Key and Strike
The new innovative VENTLOCK acts as a major deterrent to snatch thieves who spot what they consider is an easily opened window. Fitting is simple, just screw/insert it into the appropriate diameter drill hole. The special key which is supplied as part of the VENTLOCK system releases an inner barrel which prevents the window from being moved. The barrel revolves freely preventing it from being cut. The VENTLOCK is competitively priced against existing window locks. Each VENTLOCK includes a steel operation key and a brass strike plate for mounting on the lower sash check rail.
MEETS: ASTM F 2090 Standard Specification for Window Fall Prevention Devices With Emergency Escape (Egress) Release Mechanisms
Vent Lock with Key and StrikeMIGHTON
Part Number: S1015 Residential SafeGard 2R - Current Style.
**Important: Review all information below, pictures along with pdf of truths installation instruction (pdf link below) to ensure WOCD will work on your casement window.
Amesbury Truth Residential SafeGard™ 2R Operating Control Device (WOCD) For Casement Windows
The easy to operate SafeGard 2 is designed to limit the window opening to less than 4”. Designed to allow for factory installation as well as field application by trained personnel. Fits in the standard hinge cavity of 0.719"W x 0.438"H (nominal) see picture figure 3 for more information. (If your window does not have his hinge cavity this WOCD will NOt work on your window). Arm assembly has a decal with simple operating instructions, and track is assembled with visible colored plastic to discern the separate operations.
This patented releasable limit device for windows meets the ASTM F2090 (window fall prevention) safety requirements for self-resetting, egress capable, fall prevention devices.
Handing: Left Hand (Stamped with letter "A") or Right Hand (Stamped with letter "B")
****Determine handing by the hinge side of your window from the exterior. When looking at your window from the OUTSIDE of your home if it is hinged on the LEFT then you need a LEFT Hand WOCD)****
Style: We recommend to check with your window manufacture which style to purchase for your window.
R2 Standard -Track (with black clip and red button): 8 11/16 Inch Long x 3/4 Inch Wide x 1/4 Inch Deep
R2 Narrow - Track (with black clip and red button): 7 1/16 Inch Long x 3/4" Wide x 1/4" Deep
(For comparison the old Gen 1 Safegard Style with Red clip that is no longer available size was: 6 3/8" Long x 3/4" Wide X 1/4" Deep
C2 For pricing and to order C2 Commercial WODC for 5/8” cavity please email us with how many Left and and Right hand you would want for quote - factory minimums would be required.
Truth Installation Instructions:
Safeguard 2R Installation Instructions PDF
Ordering Instructions for SafeGard 2R: Residential Applications
1. Determine window handing by viewing from the outside looking in. If the casement window hinge is on the right side, you need a right hand limiting device.
2. The self-locating sash device is designed for a 7/16 in. [11 mm] cavity. Ensure there are no lips or ribs that would block the ability of the sash device to engage with the frame device. Consult the window manufacturer or application if cavity is larger than 7/16 in. [11 mm] or if lips /ribs are present, or if the cavity height on the jamb is significantly different than the sill. Shims may be required.
2.1. Locate the hinge cavity by finding where the hinge arm attaches to bottom of sash. Follow this cavity around the corner of the sash to the vertical sash member
2.1.1. If there is no cavity on the vertical sash member, please consult with your window manufacturer for application review.
Includes: Arm Assembly, Track Assembly, Template, Window Label, Screw Pack (4 screws) and Operating and Installation Instructions. (Recommended screws are #8 Pan Head, Length and screw type depended on application).
Product Highlights
Product will limit the window opening to less than 4” and requires two actions to release the device allowing the window to open fully for egress purposes
WOCD and egress release will not reduce the open area of the window unit beyond applicable code requirements
Avoids interference with operation or performance of a window
Features and Benefits beyond ASTM F2090-21
Fully concealed unit after installation and window in closed position
Easy and accurate installation in the factory or field for residential applications (SafeGard™2R) and factory or field commercial applications (SafeGard™2C)
Built-in forgiveness with field adjustment feature and allowing for up to 1/8” sash sag
All adjustments can be done inside the home after window is installed
Pan head screw (SS) use for ease of handling
Concealed arm after released from track
Window Opening Control Devices as required by ASTM F2090-21, the standard specification for window control devices with emergency (egress) release mechanisms
Actions to release the device for egress purposes are to be performed without the use of keys, tools or special knowledge
WOCD will automatically re-latch when window is fully closed
Recommended Mounting Screws. #8 Pan Head, length and screw type dependent on application
Safegard 2R Residential Application Info:
As a market leader in fenestration hardware, AT engineered, patented, and manufactured a releasable limit device for windows which meets the ASTM F2090 safety requirements for self-resetting, egress capable, fall prevention devices. The ASTM F2090 addresses window fall prevention that helps protect against potential falls by children through open windows. This is done by allowing the window opening to be set at a predetermined position of fewer than four inches (4”) and automatically re-latch when fully closed. AmesburyTruth’s SafeGard™ 2R provides a means that the window, when opened in an initial operation, will limit the venting to less than 4”. By code, two actions are required to open the window fully for egress purposes. This additional operation can be performed without the use of keys, tools, or special knowledge. SafeGard™ Window Opening Control Device is designed to allow for factory installation as well as field application by trained personnel.
PRODUCT TIPS 1. We recommend that a casement WOCD be used in casement application where applicable and building codes require such application. Please check the local building codes for applicability and egress size requirements. 2. Casement WOCD can be factory installed or field retrofit on all profile material types where standard/nominal (0.719” W X 0.438”H) hinge cavity is available. Please observe all safety instructions and consult window manufacturer when you have questions or concerns. Please contact sales for application to ensure form, fit, and function for your specific window application 3. Standard 2 walls (vinyl, fiberglass, aluminum, and other composite materials) on the profile are required for proper screw retention 4. Correct handing with proper installation is important to ensure proper operation of the device
ARCHITECT SPECS Window Opening Control Devices as required by ASTM F2090-21, the standard specification for window control devices with emergency (egress) release mechanisms. Product will limit the window opening to less than 4” and requires two actions to release the device allowing the window to open fully for egress purposes. Actions to release the device for egress purposes are to be performed without the use of keys, tools, or special knowledge. WOCD will automatically re-latch when window is fully closed. This WOCD shall be “SafeGardTM Casement
The easy to operate SafeGard 2R is designed to limit the casement window opening to less than 4”. This patented releasable limit device for windows meets the ASTM F2090-21 (window fall prevention) safety requirements for self-resetting, egress capable, fall prevention devices. Arm assembly has a decal with simple operating instructions, and track is assembled with visible colored plastic to discern the separate operations. Designed to allow for factory installation as well as field application by trained personnel. Fits in the standard hinge cavity of 0.719"W x 0.438"H (nominal).
Meets ASTM F2090-21, with additional benefits Prohibits the free passage of a 4” diameter rigid sphere Requires two separate actions to release the mechanism WOCD and egress release will not reduce the open area of the window unit beyond code requirements Avoids interference with operation or performance of window Fully concealed when window is closed Easy, accurate factory install. Field adjustment features allows for up to 1/8” sash sag adjustment from inside the home Suitable for wood, composite and vinyl windows
Window Type
Casement
Window Material:
Wood
Composite
Vinyl
Recommended Mounting Screws
#8 Pan Head, length and screw type dependent on application
Field Installation Instructions from Window Manufacturers: (as always we recommend contacting your window dealer if you require more information on WOCD WindowPartsCenter.com is an after market parts company not a window manufacture).
Marvin Modern and Ultimate Casement: https://www.marvin.com/f/1019562/x/8641870a63/casement-wocd-field-applied-instructions-19916498.pdf
Current Safegard 2 Video Below
Old Style No Longer With Red Clip Video Below- this style is no longer available replacement is the S1015
Part Number S1016
ASSA ABLOY Casement Window Operating Control Device WOCD KIT with Stickers!
Packed and Sold as Kit. Kit Contains:
One (1) 11.1mm Pin Strike
One (1) Latch ( Your choice of: Left Hand or Right Hand and 4 inch or 6 inch long)
Four (4) mounting Screws
One (1) Operational Sill Sticker
One (1) Indication Glass Sticker
One (1) Installation Instructions.
ASSA ABLOY Casement Window Operating Control Devise WOCD KIT
The ultimate solution in residential window safety is now available with the connivance of an all-inclusive kit. Easy to fit with no routing required, m the ASSA ABLOY WOCD Kit is designed for use in windows with standard 11.1mm (7/16" hardware cavity).
Features:
4 inch in stock ( 6 inch Lengths available for special order email for quote)
Tested and compliant to ASTM F2090-13
Limits venting to less than 4" of opening
Comparable with standard countersunk fixing
Austenitic 304 stainless steel for enhanced corrosion resistance
Convenience of all-inclusive bagging kit for ease of installation
No fabrication required - cavity fitting
