Part Number: S3020
Amesbury Truth Premium Sliding Patio Door Handle Set Grip Dual Pull Keyed Active Style. Mortise Lock and Keeper NOT included.
Non handed: Universal handing. Curved grip handles can be mounted on faceplate for left hand or right hand operation (see video)
What's Included: 1 interior faceplate with thumb turn, 1 exterior faceplate, 2 curved handles, mounting screws. foam shim, keyed cylinder and 2 keys
Color: White (aka Satin White)
Style:
Passive Non keyed - active handle set thumb latch only no exterior keyed lock
Keyed. Active handle set with keyed exterior cylinder. Random Keyed
(If you order 2 or more and want them Keyed Alike. Add Keyed alike to shopping cart (if you order 5 handle sets and want all 5 keyed alike add QTY 5 keyed alike to shopping cart). please allow an additional 1-2 weeks for keyed alike handle sets to ship out click here for keyed alike order add on)
Dimensions:
11 5/16 Inch Long x 1 1/4 Inch Wide Faceplate
3 Mounting Screw Holes for Faceplate
4 Inch Top to Middle Mounting Screw Holes Center to center
4 Inch Middle to bottom mounting Mounting Screw Holes Center to center
6 11/16" Curved Handle Mounting Screw Holes Center to Center
This Handle Set is known to been used on: PGT Winguard Aluminum Premium Sliding Glass Door SGD780 and PGT ClassicVue Max Aluminum Premium Sliding Glass Door SGD680
Associated Accessories Sold Separately:
C1035 Amesbury Truth Gemini II PD Dual Action Mortise Lock
It is possible for door manufactures to use a different mortise lock box with this handle set. If your mortise lock box does not match the C1035 please email us pictures of your mortise lock box for ID.
Replacement Thumb Turn Only Part is available to order from our factory drop ship website https://randrwindow.forpartsnow.com/ (These parts are stocked at the factory and drop shipped directly to the customer we do not stock this part on our Wearhouse at this time) Click Here to Order Replacement Thumb Turn Only Part
Info and Handing Video: See pictures above with video
Known Part Number: 13-575STWK
PGT Part Handle Set: 78164W
Part Number: S3021
MORTISE LOCK ROUND 45-DEGREE WITH HOOK OUT PDH 21
S3021 is a Replacement Style for Adams Rite Latch 900-19525 that is no longer available
Style: Standard or Costal (Stainless)
Known to have been used on older Pella doors Vintage 1967-1990
Part Number: S3023
Patio Door Roller Assembly 1 1/4 inch Steel Wheel PDR 40 (C)
Featuring a 1 1/4 inch Steel Wheel PDR 40 (C), the S3023 Patio Door Roller Assembly offers a reliable and steadfast solution.
Material (housing): Stamped Steel or Stainless Steel
Wheel Size: 1-1/4 Inch
Wheel material: Steel
Number of wheels: 1
Sold Individually
Known to have been used on Peachtree Citation
Top panel guide rollers are recommended when replacing bottom panel rollers Part Number S3024
Part Number: S3025
Mortise Lock 1.254 Backset 45-Degree with Pocket Trim Plate
Pocket Trim Plate is riveted onto the mortise lock box
Dimensions: 4 9/16 inch Long x 7/8 inch inch wide, 1 1/4" deep from center of 45 degree cylinder to outside edge of trim plate
Mounting Screw Holes Center to Center: 3 9/16 inch
Used By Manufacturer: Fiberlux and more
Part Number: S3026
Door Mortise Lock
Deadlatch Assy. Brass Plated 45-Degree with Pocket Trim Plate
Pocket Trim Plate can be removed by removing 2 screws
45 Degree Cylinder
Dimensions: See Drawing
Mounting Screw Holds Center to Center: 5 1/4 inch
Finish: Brass Plated
Accessory Type: Security hardware
Used By Manufacturer: Malta, Sunview and more
Number Stamped on Trim Plate: 2147 2
QC-Pass 537-45 (Rev D)
Part Number S3027
Amesbury Truth House Brand Single Point Sliding Patio Door Keeper 2315
Material: Stainless Steel
Known Part Number: 2315-00 and 2315-84
Known Brands Used On: Jeld Wen and more
Part Number: S3029
Amesbury Truth DS Surface Mount Mortise Lock 45 Degree latch with face plate Deadlatch Assembly
single-point sliding door lock is the work-horse in the industry, with proven reliability and strength. We incorporate a variety of trim-plate options, making our system compatible with all standard fabrication in the market today.
Can withstand forced entry loads in excess of 1000 lbs. Hook bolt has anti-slam feature that will retract the bolt if the boor is extended Adjustable reach hook bolt is actuated by 90 degree rotation of the hub
Manufacture: Amesbury Truth
Material: Standard or Stainless
Cylinder: 45 Degree
Faceplate mounting screw holes: 4 5/8 inch center to center
Known Part Number: 555, 555-84
Have known to been used on:, Jeld Wen vinyl sliding sliding patio doors, Amsbury Truth Hardware, and more
Videos below show different part number but install principles are the same:
Part Number: S4000
sold individually
Black Polypropylene Dust Cap for hoppe multipoint mortise
Used on swing doors that have Hoppe hardware
For Latch and Deadbolt Strike and Tongue Strike
Part Number S4003 - Vertical ONLY Adjustment
Before you place your order- S4003 vertical adjustment hinges must be used with S4004 horizontal adjustment hinge (sold separately) see hinge placement guide for more details.
Adjustable Door Hinge - Set Hinge With Non-removable pin - Vertical Adjustment
Non Handed - these hinges are for Left Hand and Right Hand Doors, by removing the set screw and hinge pin and changing the handing before you install it on your door.
S4003 is a Set hinge- vertical adjustment only Pin is removable.
S4003 works in tandem with S4004 sold separately. See hinge placement diagram in pictures and watch video below.
Colors Available In Stock: Bright Brass no other finishes available *See finish note below
Discontinued Colors: Oil Rubbed Bronze, white l, Brushed Chrome, Antique Brass , Black, Satin Nickel, Polished Chrome. (if you can add to cart we still have stock. Once stock is gone colors will be NLA and will not allow you to add to cart. No returns, all sales final on discontinued colors they are sold as is and have been marked down in price for quick sale).
For Other Finish Options: You can use as a replacement option the S4009 Vertical hinge (it’s mate S4010 for horizontal adjustment) - it has multiple finishes available in stock. they do have a different screw hole pattern and the leaf leg is slightly longer so to use them you need to replace all the hinges on the door panel so it don’t bind. Link to S4010 click here****
Condition:
New - All hinges are new product
All Sales Final = any color with "All Sales Final" is a New product that has been discounted due discontinued colors All sales final No returns on as is items.
S4003 interchangeable and direct replacement for Hoppe Columbus 2-D Hinge part # S4001
To Order Guide Horizontal Adjustment Hinge See Part # S4004
Set and Guide Hinge Placement - Also See Hinge Placement Guide Drawing:
3 Hinges Per Door Panel:
Starting at top of door Top of door
Guide (Part # S4004)
Set (Part # S4003)
Guide (Part # S4004)
4 Hinges Per Door Panel:
Anytime you need 4 hinges you would just add another guide hinge
Starting at top of door Top of door
Guide (Part # S4004)
Guide (Part # S4004)
Set (Part # S4003)
Guide (Part # S4004)
Vertical Hinge Adjustment Instructions:
Using a Phillips screwdriver, first adjust the panel up or down by turning the screw marked "V" on the set hinge. When turning the screw in the direction of the arrow (counter clockwise) the other leaf will be pushed in the direction of the arrow. Automatic screwdrivers are NOT recommended. The speed of the gun may strip the heads of the screws are over adjusted.
When the vertical adjustment is turned clockwise, the non-adjustable leaf will move in the direction of the arrow. The vertical adjustment has approximately 32 turns from its extremes.
Replacement hinge for hinges with(watch video below) Pat. Nr. 5701636, Pat. Nr. 5,701,636
Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.
Known Brands: Hoppe Hardware, Hoppe Columbus, Semco, Windsor Doors and Superior Doors, Loewen Doors, Roto and more.
Matching Screws are included with each hinge.
*Finish Note: Not for Coastal or High Humidity Applications. These hinges do not come in a sea coast or stainless material, high humidity or costal application can cause hinges to corrade this is not a product defect.
IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU
How to Adjust video below
updated 7/12/23
Part Number S4004 - Guide Horizontal Adjustable Door Hinge
Before you place your order please read below and watch our how to video at the bottom of the product page to make sure you order the correct hinge you need.
S4004 is non handed you can change the handing before you install by removing the hinge pin (see picture). For Left Hand and Right Hand Doors
Hinge is made of Steel
S4004 is a Guide Hinge - Horizontal adjustment only .
S4004 works in tandem with S4003 sold separately. See hinge placement diagram in pictures and watch our video at the bottom of the product page.
S4004 is the direct replacement and interchangeable with Hoppe Columbus 2-D Hinge part # S4002 .
Colors Available In Stock: Bright Brass, no other finishes available *See Finish Note
Discontinued Colors: Oil Rubbed Bronze, white brushed chrome, Satin Nickel, Antique Brass , Black, Polished Chrome. (if you can add to cart we still have stock. Once stock is gone colors will be NLA and will not allow you to add to cart. No returns, all sales final on discontinued colors they are sold as is and have been marked down in price for quick sale).
Other Color Finish Option: You can use as a replacement option the S4010 (it’s mate S4009) - it has multiple finishes available in stock. they do have a different screw hole pattern and the leaf leg is slightly longer so to use them you need to replace all the hinges on the door panel so it don’t bind. Link to S4010 click here****
Condition:
All hinges are NEW
To order Set Vertical Adjustment Hinge See Part # S4003
Set and Guide Hinge Placement - Also See Hinge Placement Guide Drawing:
3 Hinges Per Door Panel:
Starting at top of door Top of door
Guide (Part # S4004)
Set (Part # S4003)
Guide (Part # S4004)
4 Hinges Per Door Panel:
Anytime you need 4 hinges you would just add another guide hinge
Starting at top of door Top of door
Guide (Part # S4004)
Guide (Part # S4004)
Set (Part # S4003)
Guide (Part # S4004
Horizontal Hinge Adjustment Instructions:
Always Adjust your vertical hinge first, then adjust your horizontal hinge.
Using a Philips screw driver, adjust the panel side to side, by turning clockwise to increase margins, Turn counter clockwise to decrease the margins. Horizontal hinge has approximately 7 turns from its extremes. Automatic screwdrivers are NOT recommended. The speed of the gun may strip the heads of the screws are over adjusted.
Replacement hinge for hinges with(watch video below) Pat. Nr. 5701636, Pat. Nr. 5,701,636
Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust. Never use power tools only use hand screw driver to adjust the door so you do not strip out the adjustment screws.
Matching Screws are included with each hinge.
Known to work on: Roto, Semco Doors, Hoppe Hardware, Hoppe Columbus, Windsor Doors and Superior Doors, Loewen Doors and more
*Finish Note: Not for Coastal or High Humidity Applications. These hinges do not come in a sea coast or stainless material, high humidity or costal application can cause hinges to corrode this is not a product defect.
IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU
