Awning Window Parts

Part Number S2009 Roto Multi Point Window Lock Size: "A" Measurement on Drawing comes in either 1 9/64" (29mm) or 1 26/64" (37mm) Special order item. Allow 1-2 weeks - no returns

Read more less

Part Number:  SP15486 Sold in: 50' length for $85.00 - Free Shipping Color: Beige or Black Amesbury Truth Kerf D-rectangle weather foam weather strip. FDK-360 12049 and 12274Foam Filled Bulb Weather Strip Vertical - This weather strip has been used on Sierra pacific windows and doors. Sierra Pacific discontinued using weather strip as shown in the top picture - solid foam filled. Replacement Weather strip as shown in the bottom picture (foam filled with hole) and is what will be shipped out as its replacement Amesbury Truth Kerf D-rectangle weather foam weather strip. FDK-360 12049 and 12274 Returns only accepted for full uncut 50 foot rolls

Read more less

Part Number: SP15488Sierra Pacific Casement Horizontal Foam-Filled Bulb Weather StripSold in 50' length for $85.00 - Free ShippingFoam Filled Bulb Weather Strip Vertical - CSMT W/Strip Side Frame .360 Beige Off. Overall Dimensions: 37/64" w x 13/32" h Known Part Number: SP15488

Read more less

Part Number SP20001 Amesbury Truth Casement Awning UTO Escutcheon  Not a stock item please allow 2-3 weeks for your order to ship. Handing: None Color: White, Brushed Chrome, Bright Chrome, Coppertone, Bright Brass, Satin Nickel, Bronze, Oil Rubbed Bronze, Chestnut Bronze, Black, Matte Black, Antique Brass, Bright Nickel, Western Pewter.  Some colors can have longer lead times -see color chart Known to have been used on: Sierra pacific aspen and aspen 2 Casement and awning windows.  Associated parts Sold Separately:  Part Number SP20000 - UTO Lock Assembly For Casement Windows Part Number SP30000 - UTO Lock Assembly For Awning Windows Part Number SP20002 - UTO Lock Handle Part Number 137 - Operator Cover and handle Part number 119 - Casement Operator Dual Arm Part Number 147 - Casement Operator Dyad Arm Part Number 158 - Casement Operator Straight Arm Part Number  207 - Awning Operator

Read more less

Part Number SP20002 Amesbury Truth Casement Awning UTOLock Handle Not a stock item please allow 2-3 weeks for your order to ship. Handing: None Color: White, Brushed Chrome, Bright Chrome, Coppertone, Bright Brass, Satin Nickel, Bronze, Oil Rubbed Bronze, Chestnut Bronze, Black, Matte Black, Antique Brass, Bright Nickel, Western Pewter.  Some colors can have longer lead times -see color chart Known to have been used on: Sierra pacific aspen and aspen 2 Casement and awning windows.  Associated parts Sold Separately:  Part Number SP20000 - UTO Lock Assembly For Casement Windows Part Number SP30000 - UTO Lock Assembly For Awning Windows Part Number SP20001 - UTO Escutcheon Part Number 137 - Operator Cover and handle Part number 119 - Casement Operator Dual Arm Part Number 147 - Casement Operator Dyad Arm Part Number 158 - Casement Operator Straight Arm Part Number  207 - Awning Operator

Read more less

Part Number: SP30000 Awning Window UTO Lock Assembly Color: Beige Low Stock Item allow 1-3 weeks for your order to ship Known to have been used on: Sierra pacific aspen and aspen 2 Casement windows. (SP30000 will not work for casement windows please see part number SP20000 for casement  window UTO lock assembly)  Patent Pending 4507-0134 B, HCU12549xx00

Read more less

Part Number: SS10003 Roto North America HG05 10" Adjustable Hinge Kit For Casement Windows Direct replacement hinge for the HG04 Hinge Style What comes in a kit: 1 top and 1 bottom hinge track and 1 Top and 1 Bottom Hinge Arm (for 1/2” stack you will also get 2 black shims) Options for 10" Stainless Steel Adjustable Hinge Track: 10" Power Coated Washability Hinge Arm 10" Stainless Steel Washability Hinge Arm 10" Power Coated Egress Hinge Arm Stack Height: 7/16"  (For 1/2 inch order SS10020 shim) Measurements (taken at the longest and widest points): 10" Hinge Track: 9-5/8" L x 11/16" W x 5/16" D 10" Wash-ability Hinge Arms: Arm With Black Track Guide 6-1/4" long, Arm that attaches to Track Hinge Adjustment Nut 5-7/16" Long 10" Egress Hinge Arms: Arm With Black Track Guide 6-1/4" long, Arm that attaches to Track Hinge Adjustment Nut 7-3/16" Long Stack Height: 7/16" or 1/2" (1/2" No longer available SS10020 1.6 mm Sash Arm Spacer to make 1/2 inch stack ). HG05 Adjustable Wrench Sold Separately  If you need the shim only see part number SS10020 Information:  The Roto HG05 Hinge series features 10" washabilityversions as well as a 10" egress version and is suitable for mostcasement and awning window applications (wood, vinyl, aluminum,and fiberglass). They are available in both 7/16" and 1/2" stackheight versions, so there is no need for a spacer. The use of highquality materials and manufacturing processes makes this one ofthe strongest hinges on the market. The hinges are available inpowder coated steel or Stainless Steel versions. FeaturesEach hinge is equipped with Roto's quick disconnect feature thatallows for easy snap connection between the sash and frame.With a simple turn of a wrench, the hinge adjusts to compensatefor sash sag or window manufacturing variations, up to 3mm (.125).Additional holes in the hinge arms allow for installation into a bow/bay window and for adding a limiting device. PerformanceHinge arms are rounded at the edges to resist binding and thetrack/slider overlaps by 2.7mm (0.106") to prevent disengagement.The hinge slider is reinforced with a stainless steel insert for greaterrigidity and furnishes a 2mm clearance, eliminating interferencewith screws. The HG05 hinge is AAMA 904 life cycle compliant at 125 lbs. on the13" hinge and at 110 lbs. on the 10" version. Both steel versions areAAMA 907 corrosion compliant at 750 hours for powder coated andover 1000 hours for stainless steel. The hinges also pass ASTME1886 and ASTM E1996 hurricane impact testing. Known Part Numbers: HG05-7500, HG05-7501, HG05-7504, HG05-7505, HG057507, Replacement Hinge for HG04 styles

Read more less

Part Number SS10004 Roto North America HG05 13" Adjustable Hinge Kit For Casement Windows Direct replacement hinge for the HG04 Hinge Style HG05 Adjustable Wrench Sold Separately See Part # SS10002 What comes in a kit: 1 top and 1 bottom hinge track and 1 Top and 1 Bottom Hinge Arm  Options for 13" Stainless Steel Adjustable Hinge Track: 13" Power Coated Washability Hinge Arm Measurements (taken at the longest and widest points See diagram): 13" Hinge Track: 12-11/16" L x 11/16" W x 5/16" D 13" Washability Hinge Arms: Arm With Black Track Guide 6-1/4" long, Arm that attaches to Track Hinge Adjustment Nut 7-1/4" Long 7/16" Stack height. ( for  1/2" Stack Height also order SS10020 shim)  Known Part Numbers: HG05-7202, HG05-7203, HG05-7506

Read more less

Part Number SS10012 Roto handle for X Drive operators for Casement and Awning Windows  Spline: 5/16"  Number stamped on bottom of handle known to be: #OP06-1520 In Stock Colors: Blue White, Bright White, Euro White, Beige (aka Almond), Clay, Coppertone, Dark Bronze, and Black.  Special Order Colors:  Oil Rubbed Bronze, Brushed Chrome and Bright Brass. You will be notified of lead time once you place your order. Discontinued Colors No Longer Available: Old Clay - We call it "Old Clay" as it is much darker then the current "Clay" color that Roto manufactures. See color cart. How to tell white colors apart: When you have the handle on white copy paper the Euro White has a yellow hue compared to the paper, Bright White matches the color of the copy paper and Blue White has a blue tint compared to the paper (see our color cart picture). (Note the above is from comparing brand new handles. The sun can fade, change and yellow colors over time, if your handles are older try to use a handle that does not get direct or intense sunlight).  Associated Parts Sold Separately:  SS10011 Roto North America X Drive Dual Arm Vinyl Casement Operator S1062 Roto X Drive and Pro Drive Awning Window Operator SS10017 Roto 15 Inch Face Mount Track Assembly with Track Shoe 0P05100 SS10013 - Roto North America Face Mount Bracket Assembly For Vinyl Awning  For Pro Drive Version of handle see part number S1066 SS10012 is longer  and different from our S1042. Both are used on Roto North America X Drive OP06 Operators See pictures  Known To Be Used on Following Window Brands and Many More: Roto Casement and Awning Operators X Drive Operators SuperSeal Vinyl Windows and Sierra Pacific Vinyl Windows (For SuperSeal and Sierra Pacific Vinyl windows they used Euro White and Beige (almond) for their two standard colors Minnkota Windows (their "clay" color was the old clay that has been discounted by the manufacture).   PeachTree (their "clay" color was the old clay that has been discounted by the manufacture). Euro Star Windows & Doors WeatherShield Visions 3000 & 3500 series windows. Factory windows from Visions was "tan" which matched the offering from  (WindowPartsCenter) listed as "beige"  crestline windows  RC Home Showcase Windows CM100 Series  Royal Window and Door Profiles royalplast Allsco 4700 PREMIUM Paradigm Windows 8 -series  Known Part Number: SS10012 and OP06-1520, 7-1877W, 7-1877AD, 7-1877BW, 7-1877DB

Read more less
