Part Number 964 - Nailing Fin Corner Pad
window installation supplies
For additional protection to prevent water from going in behind nail fin (use corner pads with normal flashing and install practices)
Sold In: Set Of 4 as shown in picture
Color: Black
Stick On
Part Number 329
Sash Lifts or Sash Handle for Double Hung and Horizontal Sliding Windows
Zinc Die Cast
Brand: Amesbury Truth / Truth Hardware
Comes With 1 sash lift
Low Stocked Colors: White, Bronze and Coppertone - May have a 1-4 week lead time and special order item no returns
Discontinued Colors: Bright Brass have been discontinued
Used on Hurd, Weather Sheild and may other Single Hung and Double Hung Windows. Known Hurd Part Number 013777, Allsco 211
Screws not included
Part Number: 980
VINYL Double Hung Block Tackle Pivot Bar
Sold Individually
Dimension: 2.5 inch long x 5/16 inch wide x 3/16 inch thick
Stamped on Bar: 265 A
Known to have been used on: Hurd VINYL Double Hung Window ONLY Block & Tackle Pivot Bar, and other window brands
Part Number S1118
Double Hung Jamb Liner Friction Shoe - Locking Clutch for jamb liner
Sold white style was discontinued in September 2018. Current style is the Tan see pictures
Sold as a set of 2 - 1 Right Hand and 1 Left hand
reference part number WB1395-058.
Known To Have Been Used On: Windsor, Shelter, Rivco, Pozzi and many other window brands.
952 Pile Weather Strip
Quantity: Sold by the foot or 50 foot rolls
**No returns on rolls less than 50 feet. Returns will only be accepted for full uncut rolls of 50 feet per return policy**
Used on Hurd Single / Double Hung Compression Tilt - Stiles of bottom and Bottom of Sash
Part Number S2022
Sash balance guide rivets
sold individually - bulk pricing see below
Associated parts Sold Separately:
Part Number S2021 - Rivet Tool
Part Number: SS20018
Spiral Balance Shoe
Sold individually
Color: White
Overall Dimensions: 15/16 Inch Wide x 2 1/8 Inch Long x 3/8 Inch Thick
Used on Sierra Pacific, Hurd and SuperSeal Builder Series Single Hung Vinyl Windows with Spiral balance system.
Pivot Bar for Vinyl Double Hung Windows
2 5/8" x 5/16" x 3/16"Known to be used on SuperSeal and Sierra Pacific Vinyl Windows as well as many other vinyl double hung window brands.
Part Number: 346
NOTE: Before you place your order review all information below and review all drawings and compare to your windows.
Angel Ventlock Face Fixed Single Action WOCD Window Operating Control Device
The Face Fix version is fitted into the stiles of the top sash - one on either side.
Styles: Sold as the following:
Kit Includes: 2 Lock Devises, 4 screws and 2 bumpers
Colors: White, Oil Rubbed Bronze, (Satin Chrome, Chrome, Bright Brass email for quote minimum QTY order 500).
The units are single action, so fitting two ensures compliance with ASTM F2090 2008 and 2010 The Unit is primary factory fitted as access to the sash is available prior to installation in the window frame. However, provided the sashes can be removed easily the Face Fixed version is also suitable for use where the sashes have already been installed
two screws are used to fix each unit in place. Fixing is though h the front of the unit and into the sash. The face fix version is for use on Timer, Vinyl, Aluminum and fiberglass Sashes. If not factory installed into the sash you will have to mortise out the pocket in the sash for the WOCD to insert into. You will be responsible for determining if your sash can accept the WOCD. If unsure only order QTY 1 before ordering more.
Returns: Only accepted for stock style size A Gap measurement of 1/8 inch to 5/32 inch. #346 must be in unused new WOCD See about us > Refund Policy for full return terms and conditions. No returns accepted for Bulk orders of QTY 25 of more or of the special order colors no matter the QTY.
Stamped on side of lock: VSP Patented
For More Information on Angle Ventlocks Visit Manufactures Website: https://www.angel-ventlock.com/
