Part Number: 176
176 - Amesbury Truth EntryGard (EntryGuard) Dyad (Split) Arm Casement Operator
Truth EntryGard Dyad Arm Operator. The dyad operator is also know as a hinged single arm operatorHanding Left Hand and Right Hand: See Pictures to identify the correct handing you needDetached chips can be reversed in the field.Size: "A" Measurement is 6 Inches
For other A measurement styles as shown on chart see links below to order from our Factory Parts Drop Ship website
Styles:
Link Offset Comes in Link Down as shown in picture (33/64" Measurement) and Link Up (21/32" Measurement) Link Down Option is a Stock Item and shown in picture.
For other styles shown on chart see links below to order from our Factory Parts Drop Ship website
Replacement Parts for: Hurd, Semco, Marvin (ULTIMATE AND ULTIMATE WOOD CASEMASTER DISC LA PRE 2010), Cascade, Caradco, BiltBest, Milgard, Sierra Pacific, Allsco and more.
Screw Recommendation (screw not sold with item): 5 - #8x 1" Phillips flat head wood screws
Associated parts Sold Separately:
Part Number S1004: Truth EntryGard Cover and Nesting Handle
Part Number 139: Handle Roto Crank - 3 1/2" with 11/32" Spline
Part Number 166: EntryGard Plastic Covers
Known Part Number: 45275, PAT. NO. 4.840.075, 31368, 10815400, 10815401, 15-76-00-001, 15-76-00-002, 36-177, 36-178
Other Arm Sizes Links to Order Read chart in pictures above to determine your A Measurements match part numbers on chart to links below:
Click here to order 36-177MOD
Click here to order 36-178MOD
Click here to order 36-193
Click here to order 36-194
Click here to order 36-199
Click here to order 36-199CG
Click here to order 36-200
Email for Quote 36-200CG
Info on our parts catalog factory direct website
Cut Sheet for EntryGard Dyad Arm Casement Operator 15 Series
Part Number 114
Sash track for casement window. Track Only (Sliding track shoe p/n 189 not included)
Color: Beige (Replaces Black) May receive beige or black depending on stock.
Dimensions: 14 1/2" Long X 14/16" Wide X 19/32" Tall
Amesbury Truth 11576.XX
#8 x 1 Flat Heat Sheet Metal Screw recommended by manufacturer (not included)
Related Products Sold Separately:
Part # 101 - Amesbury Truth Maxim DLX Sill Mount Casement Dual Arm Operator
Part # 187 - Sash Bracket with Set Ring - elbow arm of #101 operator snaps onto
Part # 189 - Track Shoe – what the long arm of the #101 operator snaps onto
Part # 121 - Adjustable Hinge – below the operator on the bottom and on top of the window when you open it.
Part # 119 - Newer Encore Operators are a direct replacement/upgrade for these. See part number 119
Part Number 108
Casement / Awning Hand Knob
Fits Truth Operators 11/32" Spline OnlyColors: GoldTone, White, Bright Brass, Bronze, Clay, Aluminum, Chestnut Bronze, Beige, Coppertone
Bulk Discounted Applied in My Cart:
QTY 10-19 12%
QTY 20-39 19%**
QTY 40-79 25%**
QTY 80+ 29%**
**Orders of QTY 20 or more are considered specials order no returns.
