Part Number: S4012 – Guide Hinge
Hoppe Adjustable Hinge - Guide Hinge - Non Removable Pin Style.
S4012 is Horizontal Adjustment Only (Watch video and read instructions in picture's)
No Screws Included, sold individually
GUIDE HINGES ARE NOT HANDED. Will work on both LH and RH Doors by how you mount the hinge
If not in stock - Pre Order - Special order item - no return 3-8 week lead time
Material: Made out of Brass or Aluminum.
Finish: Multiple finishes to choose depending on material used. Aluminum is a painted finish where Brass is a living finish. Example : Oil Rubbed Brass is a live finish - each hinge finish is unique and will naturally develop a patina, changing its color and depth over time- this is NOT a finish defect.
Designed for a Greater Advantage • To Adjust vertically (Use Set Hinge Part # S4011) and for horizontally (Use Guide Hinge Part # S4012) by 1/8" for a perfect swing. See Installation Set and Guide Hinge Placement • Brass hinges feature finial caps as shown • Aluminum hinges feature flush caps. • Large 3/16" hex head screws make adjustments effortless. Remove the finial in the set hinge to access the hex screw. • Single pass routing for quick and easy installation. • All Set and Guide Hinges are equipped with non-removable pins for security, making HOPPE Adjustable Hinges the ideal solution for both inswing and outswing doors. • Especially designed for larger doors, with a panel weight capacity of up to 330 lbs. Tested to a Higher Standard • Brass hinges are tested beyond an impressive 2.5 million cycles, in accordance with ANSI A156.1 Grade 1 – Commercial test procedures. • Backed by HOPPE's Limited Lifetime Mechanical Warranty. Finished with Superior Quality HOPPE's Brass and Aluminum Hinges are outstanding corrosion resistant materials HOPPE uses their Resista® Limited Lifetime Finish Warranty on four of their select premium finishes. The Aluminum Hinges have a high quality powder coating finish.
Installation Set and Guide Hinge Placement: 3 Hinges Per Door Panel Up to 165 lbs: Starting at top of door Top of door
Guide (Use Part# S4012)
Set (Use Part# S4011)
Guide (Use Part# S4012)
4 Hinges Per Door Panel Up To 165 lbs: Starting at top of door Top of door
Guide (Use Part # S4012)
Guide (Use Part # S4012)
Set (Use Part# S4011)
Guide (Use Part # S4012)
4 Hinge Per Door Panel 165-330 lbs Starting at top of door Top of door
Guide (Use Part # S4012)
Set (Use Part# S4011)
Set (Use Part# S4011)
Guide (Use Part # S4012)
5 Hinges Per Door Panel Up To 165-330 lbs: Starting at top of door Top of door
Guide (Use Part # S4012)
Guide (Use Part # S4012)
Set (Use Part# S4011)
Set (Use Part# S4011)
Guide (Use Part # S4012)
The Set hinge no matter what is always the 2nd from the bottom Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust. Known to have been used on Sierra Pacific Doors and Ashworth
Part Number: S4115
Peachtree W&F Peachtree Citadel Swing Patio Door Multipoint Lock Aux Module
This is designed to be field reversible. The latch is two
stage, it operates first as a latch, then further extends to
be a deadbolt. But the housing is symmetrical and the latch
is removable. It can be operated for Left hand or Right Hand, inswing or outswing swing doors.
Associated Parts Sold Separately:
D301 W&F Trilennium multipoint 6 Inch CTC Replacement Handle Set
S4112 - Peachtree Multipoint Mortise Lock Citadel IPD Citation W&F
Part Number D309
Keyed Cylinder for Trilennium, W&F and Endura handle sets
Each kit comes with 1 keyed cylinder and 2 keys
Style: Schlage or Weiser
Random Keyed: Means if you order 1 or more each cylinder will use a different key
Keyed Alike: means if you order 2 or more they will all use the same key
Size: 1 3/4 Inch (door panel thickness) or 2 1/4 Inch (door panel thickness)
Color: Satin Chrome (US26D) or Oil Rubbed Bronze (US10B) (ORB only available in Schaleg style)
Part Number 881
GU Multi Point In Swinging Door Strike
Colors: Stainless Steel and Oil Rubbed Bronze
Discontinued colors:
All other colors below have been discontinued and no longer available. Any stock we still have is AS IS no return.
Antique Brass
Bright Brass
Polished Chrome
White
Screws Not Included: Factory Recommends using 7 x 5/8 PH FH Screw
Known to be used on: GU, Hurd and Sierra pacific WI in-swinging wood/clad doors.
Part Number: S4015 - Truths Sentry Adjustable Hinges - Guide Hinges
If not in stock but a preorder item then it’s a Special order Item No Returns
Screws Not Included
Engineered for maximum strength and security, Sentry Hinges exceed ANSI grade 3 requirements fordoors weighing up to 220 lbs. Sentry Hinges exceed ANSI grade 1 impact specifications. Sentry Hinges aremade of extruded brass and extruded aluminum that provides superior strength and corrosion resistance.Sentry Hinges provided with non-removable pins for maximum security.
Robust, Reliable and Attractive
Industry standard 4" x 4" with 5/8" radius corner
Both Guide (Part # S4015) and Set (Part # S4016) Hinges take a 5/32" hex wrench
Guide Hinge (Part # S4015) has a 11/64" adjustment and Set Hinge (Part # S4016) has a 1/4" adjustment
Extruded brass hinges are provided in decorative finishes including PVD
Extruded aluminum hinges are available in powder coated painted finishes
Composite bushings provide noise-free operation
Set and Guide Hinge Placement:
3 Hinges Per Door Panel:
Starting at top of door Top of door
Guide
Set
Guide
4 Hinges Per Door Panel:
Anytime you need 4 hinges you would just add another guide hinge
Starting at top of door Top of door
Guide
Guide
Set
Guide
The Set hinge no matter what is always the 2nd from the bottom
Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.
Part Number: S4013
Hoppe Millennium Adjustable Hinge - 2-D Set Hinge with Non-removable Pin Vertical Adjustment - Hinges are Non Handed. Works for both Left hand and Right hand swinging doors. Known to been used on WeatherSheild and Peachtree Doors
Colors Still Available: Stainless Steel
Discontinued Colors: Oil Rubbed Bronze, Brass Chrome, antique brass
Pat.Nr. 5.701.1636, 122210600
Set and Guide Hinge Placement Table:
3 Hinges Per Door Panel - Up to 165 lbs:
Starting at top of door Top of door
Guide - Part Number S4014
Set - See Part Number S4013
Guide - Part Number S4014
4 Hinges Per Door Panel -Up to 165 lbs:
Anytime you need 4 hinges you would just add another guide hinge
Starting at top of door Top of door
Guide - Part Number S4014
Guide - Part Number S4014
Set - See Part Number S4013
Guide - Part Number S4014
4 Hinges Per Door Panel - 165 - 330 lbs:
Starting at top of door Top of door
Guide - Part Number S4014
Set - See Part Number S4013
Set - See Part Number S4013
Guide - Part Number S4014
5 Hinges Per Door Panel - 165 to 330 lbs:
Guide - Part Number S4014
Guide - Part Number S4014
Set - See Part Number S4013
Set - See Part Number S4013
Guide - Part Number S4014
Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.
Known part # 850-2388803, 850-8754819, 122210600
General HOPPE Adjustable Hinge Adjustment Instructions:
Determine hinge locations on the frame and door panel. Recommended hinge positions are given in the Set and Guide Hinge Placement Table above.
Prepare the door panel and frame.
Fasten hinges into the door panel. #10 ANSI wood screws with a minimum length of 1 1/4” are recommended. The Set Hinge must be installed according to the installation label. The label on the frame leaf will point down to the sill when properly installed.
On the frame, use #10 ANSI wood screws that are 5/8” to 3/4” long in three of the four screw locations. One screw on each hinge should be at least 1 1/2” long to reach the stud. This screw is typically left out and is installed after the door is positioned in the rough opening.
Install the frame leaf of the Set Hinge into the routing on the frame and fasten securely. Do not allow the Set Hinge(s) to support the weight of the panel without installing the Guide Hinges.
Install the frame leaf of the Guide Hinges into the routings on the frame and fasten securely. Leaves on the Guide Hinges will slide freely up and down for alignment with the rout.
Do not adjust hinges prior to the final installation into the rough opening. This will affect the ability of the door installer and end user to utilize the full adjustment range of the HOPPE Adjustable Hinge.
Disassembly
Do not attempt to remove the hinge pin, as this may cause damage.
To disassemble the door panel from the frame, support the weight of the panel to relieve the weight from the hinges.
Carefully remove either the frame leaf screws or door leaf screws to displace the panel.
Adjustment InstructionsIntroductionThere are two types of HOPPE Adjustable Hinges on each door panel:
Set Hinge: One or two per panel. The Set Hinge provides ± 1/8” vertical adjustment.
Guide Hinge: Two or three per panel. The Guide Hinges provide ± 1/8” horizontal adjustment. Look for the visible adjusting screw on the door sash leaf. This identifies the hinge as a Guide Hinge.
Hinge designs may vary, but adjustment remains the same.
Required Tools
A 3/16” hex wrench is required.
A small flat head screwdriver is required.
A plastic putty knife is recommended.
Vertical Adjustment for Doors with One Set HingeWith the door closed or open:
Remove the press-fit Finial Cap from the bottom of the Set Hinge to expose the adjustment screw. Use the small screwdriver for Set Hinges featuring a plastic Finial Cap. A plastic putty knife is recommended for Set Hinges featuring a brass Finial Cap.
Insert the hex wrench into the bottom of the Set Hinge. Tighten the screw to raise the panel and loosen to lower the panel.
Reinstall the Finial Cap removed in Step 1.
Vertical Adjustment for Doors with Two Set HingesWith the door closed or open:
Remove the press-fit Finial Cap from the bottom of the Set Hingeto expose the adjustment screw. Use the small screwdriver forSet Hinges featuring a plastic Finial Cap. A plastic putty knife isrecommended for Set Hinges featuring a brass Finial Cap.
To raise the panel, insert the hex wrench into the top-most SetHinge and tighten the adjustment screw to achieve the desiredInsert the hex wrench into the other Set Hinge andtighten the adjustment screw 1/8 turn past the onset of resistanceto distribute the panel weight evenly between both Set Hinges.
To lower the panel, insert the hex wrench into the top-most SetHinge and loosen the adjustment screw as far as possible withoutInsert the hex wrench into the other Set Hinge andloosen the adjustment screw to achieve the desired adjustment.Retighten the adjustment screw on the top-most 1/8 turn past theonset of resistance to distribute the panel weight evenly betweenboth Set Hinges.
Reinstall the Finial Caps removed in Step 1.
Horizontal AdjustmentWith the door open:
Insert a 3/16” hex wrench into the horizontal adjustment screw.
Turn clockwise to decrease the margin and counterclockwise toincrease the margin on the hinge side.
IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU
Part Number: D300* - 1 handle set will install on 1 door panel. If you have 2 door panels (like a French door) you will need to order 2 handle sets.
W&F Trilennium 6 Inch CTC multipoint bore D300 is the new Replacement Handle Set - Non stock item special order - Estimate 1-2 weeks for your order to ship (unless otherwise noted on our website about extended lead times) - No order cancellations or returns
D300 is for doors with: 6 inch center to center 1 7/8" or 2 1/8" diameter bores and mounting screw hole placement 5 3/8" Center To Center.
Requires: 1 11/16" or 2 1/8" cross bore
Model: D300 Standard Set**
Screw Hole Placement: 5 3/8" Center To Center
Size: for Door Thickness 1 3/4" or 2 1/4"
Colors: Victorian Bronze, Bright Brass, Satin Nickel, Black
Handing: Universal - Non handed. Works for both LH and RH swing doors depending on which lever you use for the exterior and interior.
Style:
Active Standard 150 Degree- Has Thumb Turn, Keyed Cylinder and Lever is Operational*** For Single and French Active door panels. (Degree is how far the lever handle rotates for newer style multi point see pictures)
Dummy - No Thumb Turn, No Key Cylinder and Fixed Lever**** For Inactive panels in French doors - that is fixed or has independent astragal installed
Tumbturn for 3020 - Has Thumb Turn, No Key Cylinder and Fixed Lever**** For Inactive panels in French doors that has 3020 lock installed only***
Active Modified 180° Option (Add-On)
This option modifies the lever handle to rotate 180°, which is required for some older multi-point and double bore systems. (See product images for examples of lever rotation.)
How to order:This is an additional add-on and must be selected under “Accessory Items.”
If you order 1 handle set → add Qty 1 of the 180° modification
If you order 3 handle sets → add Qty 3 of the 180° modification
Each handle set that needs this modification requires its own quantity.
Handle Sets have been known to have been used on Bayer, Pella, Peachtree and other door brands.
Known W&F old handle set Pat No. 4,671,089 stamped on back of trim plate
Notes for other options for this style hardware on older doors:
D300 is manufactured for the current multipoint system and will work for you right out of the box - order Active Standard 150 Degree (see pictures).
If you have older style multipoint or backset lock and dead bolt with 6” center to center bore and screw hole placement is
5 3/8" Center To Center then Active Modified 180 Degree (see pictures)
If your door has a 6 inch center to center 2 1/8" standard double bore with back set latch and dead bolt and screw holes are also 6" center to center you need to order part number 852).
If you are not sure what type of system your door has, please send us pictures of your handle set with the door panel open so we can see the hardware that the handle set connects to inside the panel. Email pictures to: info@windowpartscenter.com
footnotes:
Non stock - Estimated 1-2 week for your order to ship - No order cancellations or returns
*Active Modified 180 Degree bushing or cartridge has no manufacturer warranty
Warranty claims are handled on a case by case basis by the manufacturer. Pictures need to be emailed to info@windowpartscenter.com to submit a warranty claim for factory to review.
This handle set also comes in other Models: See part numbers: D300, D301, D302, D304
Operational Lever: Can move up and down when door is unlocked
Fixed Lever: Inactive, and is intended for push/pull function.
Do NOT use a power driver tool to attach the handle set face plate retaining screws. Thread damage can result and is NOT considered a product defect.
Associated Parts Sold Separately:
S4112 - Peachtree Multipoint Mortise Lock Citadel IPD Citation
For Trilennium Multi Point - Email us for quote. Info@WindowPartsCenter.com
Part Number: S4016 - Truths Sentry Adjustable Hinges - Set Hinges
If not in stock but a pre order item then it’s a Special order Item No Returns
Screws Not Included
Engineered for maximum strength and security, Sentry Hinges exceed ANSI grade 3 requirements fordoors weighing up to 220 lbs. Sentry Hinges exceed ANSI grade 1 impact specifications. Sentry Hinges aremade of extruded brass and extruded aluminum that provides superior strength and corrosion resistance.Sentry Hinges provided with non-removable pins for maximum security.
Robust, Reliable and Attractive
Industry standard 4" x 4" with 5/8" radius corner
Both Guide (Part # S4015) and Set (Part # S4016) Hinges take a 5/32" hex wrench
Guide Hinge (Part # S4015) has a 11/64" adjustment and Set Hinge (Part # S4016) has a 1/4" adjustment
Extruded brass hinges are provided in decorative finishes including PVD
Extruded aluminum hinges are available in powder coated painted finishes
Composite bushings provide noise-free operation
Set and Guide Hinge Placement:
3 Hinges Per Door Panel:
Starting at top of door Top of door
Guide
Set
Guide
4 Hinges Per Door Panel:
Anytime you need 4 hinges you would just add another guide hinge
Starting at top of door Top of door
Guide
Guide
Set
Guide
The Set hinge no matter what is always the 2nd from the bottom
Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.
As is - New Condition old stock (may have minor scuffs, etc.) - No returns all sales final. Once our stock is gone this item will no longer be available.
840-008 - Amesbury Truth GU Handle - Set Screw and Shaft Type - Swinging Patio Door Hurd.
Replacement handle only. All other replacement parts sold separately.
Discontinued Product. What we have in stock is all that is available. No returns, all sales final. Some may have minor scratches.
