S4004 - Horizontal Adjustable Guide Door Hinge

Description

Parrt Number S4004.

 Before you place your order please read below and watch our how to video at the bottom of the product page to make sure you order the correct hinge you need.

Guide Horizontal Adjustable Door Hinge -  Guide Hinge For Left Hand and Right Hand Doors

S4004 is non handed you can change the handing before you install by removing the hinge pin (see picture).

Hinge is made of Steel

  • S4004 is a Guide Hinge - Horizontal adjustment only . Comes in multiple finishes
  • S4004 works in tandem with S4003 sold separately. See hinge  placement diagram in pictures and watch our video at the bottom of the product page.

S4004 is the direct replacement and interchangeable with Hoppe Columbus 2-D Hinge part # S4002 .

Colors Available In Stock: Bright Brass, no other finishes available *See Finish Note

Discontinued Colors: Oil Rubbed Bronze, white  brushed chrome, Satin Nickel, Antique Brass , Black, Polished Chrome. (if you can add to cart we still have stock. Once stock is gone colors will be NLA and will not allow you to add to cart. No returns, all sales final on discontinued colors they are sold as is and have been marked down in price for quick sale).

Condition:

  • All hinges are NEW
  • any color with "As Is" added = New product that has been discounted due to one or more of the following: color or finish maybe discontinued, old stock,  minor finish flaws or scratches.  This item may be a customer return, vendor sample, or came in from the factory with finish flaws.  In some instances, these items are repackaged. All sales final. No returns on as is items.

To order Set Vertical Adjustment Hinge See Part # S4003

Set and Guide Hinge Placement - Also See Hinge Placement Guide Drawing:

  • 3 Hinges Per Door Panel:
    • Starting at top of door Top of door
      1. Guide (Part # S4004)
      2. Set (Part # S4003)
      3. Guide (Part # S4004)



  • 4 Hinges Per Door Panel:
    • Anytime you need 4 hinges you would just add another guide hinge
    • Starting at top of door Top of door
      1. Guide (Part # S4004)
      2. Guide (Part # S4004)
      3.  Set (Part # S4003)
      4. Guide (Part # S4004

Horizontal Hinge Adjustment Instructions:

Always Adjust your vertical hinge first, then adjust your horizontal hinge.

Using a Philips screw driver, adjust the panel side to side, by turning clockwise to increase margins, Turn counter clockwise to decrease the margins.  Horizontal hinge has approximately 7 turns from its extremes. Automatic screwdrivers are NOT recommended. The speed of the gun may strip the heads of the screws are over adjusted.

Replacement hinge for hinges with(watch video below) Pat. Nr. 5701636, Pat. Nr. 5,701,636

Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust. Never use power tools only use hand screw driver to adjust the door so you do not strip out the adjustment screws.

Matching Screws are included with each hinge.

Known to work on: Roto, Semco Doors, Hoppe Hardware, Hoppe Columbus, Windsor Doors and Superior Doors, Loewen Doors and more

*Finish Note: Not for Coastal or High Humidity Applications. These hinges do not come in a sea coast or stainless material, high humidity or costal application can cause hinges to corrode this is not a product defect.

IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU
